CETB300LC150
Closed-loop (compensated) current transducer for high-precision current measurement.
Product Overview
Closed-loop (compensated) current transducer for high-precision current measurement. Galvanic isolation between primary and secondary circuits ensures safe operaon. Capable of measuring DC, AC, and pulsed currents with enhanced linearity. Supply voltage: DC ±12V to ±15V for stable and accurate performance. High accuracy with low temperature drift, ensuring reliable readings. Optimized response time for dynamic applications. Superior immunity to external electromagnetc interference, enhancing operaonal reliability. Compact design with easy integraon into various systems.
Key Features
- Closed-loop (compensated) current transducer for high-precision current measurement.
- Galvanic isolation between primary and secondary circuits ensures safe operation.
- Capable of measuring DC, AC, and pulsed currents with enhanced linearity.
- Supply voltage: DC ±12V to ±15V for stable and accurate performance.
- High accuracy with low temperature drift, ensuring reliable readings.
- Optimized response time for dynamic applications.
- Superior immunity to external electromagnetic interference, enhancing operational reliability.
- Compact design with easy integration into various systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Current Consumption (IC) | 17 + IS mA |
| Bandwidth | DC-100 kHz |
| Operating Temperature | from -40 °C to 85 °C |
| Supply Voltage (VC) | ±12V to ±15V |
| Rated Input Current (IPN) | ±300 A |
| Measuring Range (IPM) | 0 to ±600 A |
| Accuracy @ IPN, TA = 25°C | < ±0.5% |
| Output Current (IOUT) | ±150×IP/IPN mA |
| Offset Current (IO) | < ±0.2 mA |
Compliance & Standards
- EN60947-5-1:2004+A1:2009,
- EN60947-1:2007+A2:2011+A2:2014,
- EN50155:2021
Quick Reference
- Part Number
- CETB300LC150
- Type
- Current Sensor
Applications
- Drives
- Power Supplies
- Traction
